yamatake Recorder indicator

Product Description

DigitroniK Smart Indicator
(with LED Bar Graph)

The SI is a compact, lightweight, highly reliable single-point process faceplate, featuring a DIN-sized LED bar graph indicator of process variables.
Features include high-intensity custom LEDs, three bar display colors (red, green and yellow) and simplified adjustment of alarm setting.

Compact Recorder

The CQ Compact Recorder accommodates a chart 100mm wide, and comes in two types: pen type or dot printing type. The user can also choose from four available inputs: thermocouple, resistance temperature detector, DC voltage or DC current.

Smart Recorders, 1/2/3-Pen Recording Models

The SRF201/202/203 are high-performance pen-recording chart recorders that use a chart 180mm wide. DC voltage, thermocouple and resistance temperature detector (RTD) can be applied as input signals.
Options include event outputs, external contact inputs and communications.

Smart Recorders, 6/12/24-Dot Printing Models

The SRF206/212/224 are high-performance 6/12/24-dot printing chart recorders that uses a chart 180mm wide. DC voltage, thermocouple, resistance temperature detector (RTD), communications and ON/OFF can be applied as input signals.
Options include event outputs, external contact inputs, chart illuminating lamp and communications.

Smart Recorders, 1/2/3-Pen Recording Models

The SRF101/102/103 are high-performance pen-recording chart recorders that use a chart 100mm wide. DC voltage, thermocouple and resistance temperature detector (RTD) can be applied as input signals.
Options include event outputs, external contact inputs and communications.

Smart Recorder, 6-Dot Printing Model

The SRF106 is a high-performance 6-dot printing chart recorder that uses a 100mm wide chart. DC voltage, thermocouple and resistance temperature detector (RTD) can be applied as input signals.
Options include event outputs, external contact inputs, chart illuminating lamp and communications.
